MAXPRO 5-way 3-position manual valve with spring lever 3/8 F-NPT

567-80-919
MAXPRO 5-way 3-position manual valve with spring lever 3/8 F-NPT
MAXPRO 5-way 3-position manual valve with spring lever 3/8 F-NPT

Features

  • MAXPRO model
  • 5 ways/3 positions
  • Velocity coefficient: 1.94 Cv
  • Operating pressure: 0 to 128 PSI
  • Operating temperature: -10 to 60°C
  • Compatible fluids: compressed air only (lubricated or non-lubricated)
  • Anodized aluminum body
  • Oil-resistant rubber seal
  • Aluminum spool
  • Red controller
  • Closed center

Technical Information

Actuator Type
Lever
Thread Size
3/8 in
Thread Type
F-NPT
Number of Ways
5
Number of Positions
3
Return Mechanism
Spring
Material
Aluminum
Series
MAXPRO
Type
Closed center
Temperature Rating
-10 to 60°C
Working Pressure
0 to 128 PSI
